4 - ASSEMBLY
15. Connect the existing hose (G) to the rigid boom tube (20). 16. Connect the existing hose (H) to the rigid boom tube (7). 17. Route the boom electric harness (24) along the existing hose (H) and the rigid boom tube (7) to the pressure switch (11). 18. Connect the connector “X2.p” on the boom electric harness (24) to the pressure switch (11). 19. Secure the boom electric harness (24) in place with four tie straps (12) where shown.
RAIL17TLB0216BD
19
RAIL16TLB0363BA
20
Lift hook link install 1. Remove the lower snap rings (M), the shims (N), and the pin (O). 2. Support the existing link (P). 3. Remove the upper snap rings (Q), the shims (R), and the pin (S). 4. Remove the existing link (P) from the machine.
12 EN
