4 - ASSEMBLY
6. Connect the rigid boom tube (7) to the straight fitting (4) in port “V2”
RAIL16TLB0352AA
12
RAIL16TLB0353AA
13
RAIL16TLB0354AA
14
RAIL16TLB0355AA
15
7. Connect the hydraulic hose (8) to the straight fitting (3) in port “Pil”.
8. Secure the rigid boom tube (7) to the boom cylinder with one spacer (22) and one clamp (9) as shown.
9. Connect the rigid boom tube (20) to the existing fitting (L) at the base end of the boom cylinder. 10. Connect the hydraulic hose (8) to the rigid boom tube (20).
