5 - ASSEMBLY
38. Install the straight connector (5) to the JSS cut-off valve (37). 39. Install the joystick steering tube (46) to the straight connector (5). 40. Install the 90° elbow (48) on the DR port of the JSS cut-off valve (37). 41. Install the tee (11) to the cooling frame (R). 42. Install the return brake to tank hydraulic hose (V) to the tee (11). 43. Install the cut-off valve to tank hydraulic hose (49) to the 90° elbow (48) and to the tee (11). 44. Install the plugs (47) to the JSS cut-off valve (37).
