5 - ASSEMBLY

10. Install the joystick steering LS hydraulic hose (43) to the straight connector (20).

11. Install the suction valve hose (13) to the 90° elbow (7).

12. Install the tank hydraulic hose (18) to the 90° elbow (6).

13. Install the joystick steering hydraulic tube (46) to the 90° long elbow (45).

14. Install the cylinder hydraulic hose (42) to the 45° elbow (38).

15. Install the cylinder hydraulic hose (41) to the 45° elbow (38).
