5 - ASSEMBLY
5 - ASSEMBLY Install
Hydraulic provision kit 1. Unscrew and remove the two plugs (P) from the ports (A1) and (B1) of the main control valve (MV). Discard the two plugs (P). NOTE: during this operation, place a container under the main control valve (MV) to prevent that the oil spills over the ground.
LEIL19CWL0162AB
1
2. Install the two hydraulic connectors (15) to the ports (A1) and (B1) of the main control valve (MV). 3. Install the 90° elbow (16) to the connector (15) located on the port (B1) of the main control valve (MV). 4. Connect the hose (18) to the elbow (16). NOTE: the hose (18) has the yellow plastic tie to both end. 5. Connect the hose (17) to the hydraulic connector (15) located on the port (A1) of the main control valve (MV). NOTE: the hose (17) has the orange plastic tie to both end.
8 EN
