5 - ASSEMBLY
12. Route the two hoses (14) along the right side of the loader arm. Secure the two hoses (14) to the loader arm by means of the two plates (9), the two clamps (7), the two washers (10), and the two bolts (11). NOTE: align the clamps side shown on the figures 11 or 12 (see arrows) to mark on hoses (14). NOTE: the next step changes according to the third or fourth function configuration. 13. Connect the two hoses (14) to the two 90° elbows (E). NOTE: apply the angle orientation to the hoses (14) as shown in figure 11.
LEIL20CWL1047FB
11
Third function configuration
12 EN
