2 - KIT CONTENT
2 - KIT CONTENT Kit overview NOTICE: To check the items part numbers of this kit, please refer to the Parts Catalogue. NOTE: The following table shows the items numbered as in the installation instruction.
Kit 51560399 (Z-bar version) Item 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Description Drain hose (rear frame side) Coated closed clamp 14.3 mm bolt 3/8 Washer 9 X 16 X 1.6 mm Bolt M8 X 16 Drain hose (loader arm side) Coated closed clamp 12.7 mm bolt 1/2 Cable tie Bulkhead union 6 mm or 1/4 in Bulkhead locknut 6 mm or 1/4 in 90° swivel elbow Female quick coupling Washer 11 X 20 X 2 mm Nut M10 Double loop cable tie 300 – 397 mm
Quantity 1 1 1 1 1 1 4 1 1 1 1 1 1 2
Kit 51560400 (Tool Carrier version) Item 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Description Bulkhead union 6 mm or 1/4 in Bulkhead locknut 6 mm or 1/4 in Drain hose (loader arm side) Drain hose (rear frame side) Cable tie Bulkhead union 16 mm or 5/8 in Bulkhead locknut 16 mm or 5/8 in ORFS reducing adapter ORFS tube end nut 16 mm or 5/8 in Coated closed clamp 14.3 mm bolt 3/8 Washer 9 X 16 X 1.6 mm Bolt M8 X 16 90° swivel elbow Female quick coupling
Quantity 1 1 1 1 6 1 1 2 2 1 1 1 1 1
5 EN
