5 - ASSEMBLY
18. Install the union (1) on the plate (M). Use the lock nut (2). 19. Install the drain hose (3) on the union (1). Tighten to 27 N·m (20 lb ft). 20. Install the 90° elbow (13) on the union (1). Tighten to 27 N·m (20 lb ft). 21. Install the quick coupling (14) on the 90° elbow (13). 22. Adjust the orientation of the 90° elbow (13), and the quick coupling (14) as shown in Figure 29. Tighten the quick coupling (14) to 100 N·m (74 lb ft). LEIL19CWL0303AA
28
LEIL19CWL0310AA
29
LEIL19CWL0304AA
30
23. Secure the drain hose (3) to the existing hydraulic hoses. Use the cable ties (5).
17 EN
