5 - ASSEMBLY
8. On the rear frame locate the clamps (E). Remove the hardware (H) and loosen the nut (G) to move the plate (F) and facilitate the drain hose installation.
LEIL19CWL0332AA
20
LEIL19CWL0264AA
21
LEIL19CWL0333AA
22
LEIL19CWL0334AA
23
9. Secure the drain hose (4) to the rear frame. Use the clamp (10), the bolt (12), the washer (11), and the nut (D). NOTE: Align the clamp (10) to the mark on the drain hose (4).
10. Pass the drain hose (4) through the clamps (E) as shown. NOTE: Align the mark (4b) on the drain hose (4) to the clamps (E).
11. Reinstall the hardware (H) to reassemble the clamps (E) and the plate (F). Tighten the nut (G).
15 EN
