20. Install the union (8) on the plate (N). Use the lock nut (9). 21. Install the drain hose (5) on the union (8). 22. Adjust the orientation of the drain hose (5) as shown in Figure 14, B. Tighten to 27 N·m (20 lb ft). 23. Install the 90° elbow (10) on the union (8). Tighten to 27 N·m (20 lb ft). 24. Install the quick coupling (11) on the 90° elbow (10). 25. Adjust the orientation of the 90° elbow (10), and the quick coupling (11) as shown in Figure 14, A. Tighten to 27 N·m (20 lb ft).
LEIL19CWL0286AA
13
LEIL19CWL0279AA
14
26. Secure the drain hose (5) to the existing hydraulic hoses. Use the cable ties (7) as shown in Figure 1.
