3 - ASSEMBLY
49. Heat the carrier output shaft to 120 °C (248 °F) in a bearing oven. Wearing heat resistant gloves or mittens, install the bearing on the shaft until the bearing is against the carrier gear. Coat the spline of the carrier output shaft with LOCTITE® SILVER GRADE ANTI-SEIZE 767.
LEIL14WHL0056AA
47
LEIL14WHL0077AA
48
LEIL14WHL0054AA
49
LEIL14WHL0053AA
50
50. Install a new stop pin if it was removed, damaged or worn.
51. Attach a suitable lifting device to the brake housing and insert the brake housing to the carrier output shaft.
52. Attach a suitable lifting device to the wheel hub and reinstall the wheel hub on to the brake housing. A slight rotation of the wheel hub may be necessary to align the splines on the carrier output shaft.
