PM
CMRIIC 4.
Check steer linkage for proper mounting and working condition. Make sure all cotter keys are present and in good condition.
5.
Check the steer cylinder piston rod for scratches or pitting that may cause damage to the cylinder packing. Check cylinder packing for leakage due to damage.
6.. Check hydraulic hoses for proper routing or any damage that could cause leakage. Also check hydraulic fittings for tightness.
Fig. 19445
DRIVE MOTO,RS: 1.
Refer to GROUP 38, Section 3 for proper procedure to jack and block truck wheels up off floor.
2.
With truck already blocked up, disconnect battery, loosen screw and remove brush cover plate from end of drive motor, under the truck. Using moisture-free compressed air, blow off inside of motor around commutator and brushes. CAUTION REDUCE AIR PRESSURE BELOW 30 PSI, WEAR ! P SAFETY GLASSES AND PROTECTIVE EQUIPMENT WHEN: CLEANING WITH COMPRESSED AIR.
Code: PM-502, AUG 84
Fig. 19465
Page 25 Copyrighted Material Intended for CLARK dealers only Do not sell or distribute
