Prior to operation DISCO 8550 C Plus / 8550 C / 8550 C-T:
DISCO 8550 C Plus / 8550 C / 8550 C-T
• Connect the hydraulic lines (7) to hydraulic ram (2).
• Unscrew the drain plugs from the elbow 10
support (10) had and connect the hydraulic hoses (7) to the centre mower.
7
(Fig. 26, 27) DISCO 8500 C:
• Connect the hydraulic lines (7) to hydraulic 10
ram (2).
7
• Connect the hydraulic lines (7) to flow divider (9) using T-union (8).
26
(Fig. 28) DISCO 8550 C Plus / 8550 C / 8550 C-T
7
10
2
68291M01
0293 653.8 - ZBA+BA DISCO 8550 C Plus / 8550 C / 8550 Plus / 8550 / 8550 C-T / 8500 C
27
6.11
