74693
7 Angle drive (E) Gearbox capacity: – see Lubricants chart, page 9.14 11 = oil drain plug 12 = oil filler and oil level check plug 12 (Fig. 7, 8) 11
63328
8 Rotor drive (F) Gearbox capacity: – see Lubricants chart, page 9.14 13 = oil filler and oil level check plug 14 = oil drain plug (Fig. 7, 9)
13
14 9
