Maintenance
B
A
74693
1 Spur wheel gear (A) Gearbox capacity: – see Lubricants chart, page 9.14 1
1 = Oil filler and vent screw 2 = Oil level check screw 3 = Oil drain plug
2
(Fig. 1, 2)
3 2 Angle drive (B) Gearbox capacity: – see Lubricants chart, page 9.14 4
4 = Oil filler screw 5 = Oil level check screw 6 = Oil drain plug CAUTION!
5
Check oil level only with fully raised maize header. 6 74695
9.3
3
(Fig. 1, 3)
ABA/BA RU 600 Contour / Auto-Contour - 0293 623.0
