Operation
1
2
3
5 3 4
8
7 6
9 10
6 4
11 10
12
3 3
6
2
9 1 8
14 3 13
15
3 3 4 74736
Deflector bar height increase (D03 0060)
21
Order no.: 0999 182.0 When harvesting very high maize, increasing the deflector bar height can improve the intake of the crop. Mount deflector bar height increase as shown in Fig. 21. NOTE! Before folding the maize header, remove detachable tube (8) on left and right. 1 Connector 12x96 ................................................ 2 2 Hexagon screw M10x100 ................................... 4 3 Contact washer A10 ......................................... 20 4 Hexagon nut M10 ............................................... 8 5 Outrigger pipe, right ........................................... 1 6 Contact washer A12 ........................................... 8 7 Hexagon nut M12 ............................................... 4 8 Detachable pipe ................................................. 2 9 Cross pipe ......................................................... 2 10 Hexagon bolt M12x70 ....................................... 4 11 Intermediate pipe 40x 3x 400 ............................. 1 12 Outrigger pipe, left ............................................. 1 13 Hexagon bolt M10x40 ........................................ 4 14 Hexagon bolt M10x50-Mk .................................. 4 15 Bush 22x4.5x 33................................................. 4 (Fig. 21)
8.9
ABA/BA RU 600 Contour / Auto-Contour - 0293 623.0
