8 Operation DANGER! Carry out work under and on the raised maize header only after having propped it safely. – see Safety prop on page 5.7 Carry out work on the maize header only with the drive switched off and the engine at standstill. – Remove the ignition key. – Switch off the battery master switch.
USE DANGER! Never stand in the danger zone while lifting, lowering the maize header or while folding the side arm of the maize header. – Make sure nobody is in the danger zone.
Raising and lowering the maize header
JAGAUR 900, 890, 870, 850, 830
With the multifunction lever:
• By pressing the tip switch (1a)
R
– Lower maize header.
• By pressing the tip switch (1b)
1a
– Raise maize header. 1d
• By tapping the tip switch (1d)
1b
– Switch on contour system.
70798A
1
NOTE! Press tip switch (1a, 1b) to switch off the Contour system. (Fig. 1)
8.1
