Assembly instructions
Assembly instructions Operation Attention! The baler can be connected to all tractors which are fitted with a standard hydraulics system.
Tractor with continuous flow hydraulic system or with Load Sensing system without "Power Beyond" T
Attention!
P
Activating functions via Claas Communicator while hydraulic circuit is not yet pressurised: – Very serious injury – Extensive damage to bale wrapper 1
☞ Ensure that Claas Communicator is
switched off before starting tractor engine.
☞ Ensure that Claas Communicator is
switched off before pressurising hydraulic circuit.
☞ Always start up Claas Communicator after first starting tractor engine and pressurising hydraulic circuit.
– Connect up coupler (P) to a distributor on tractor. – Slacken screw (V) on hydraulic block as far as possible, in order to activate baler's pressure compensation.
V
– Connect up coupler (T): – to unpressurised male stud adapter (direct instroke to tank) if tractor allows it (greasing of gearbox is assured). – to dual action distributor on tractor. 2
Attention! If tractor has an adjustable flow distributor, set flow to between 35 and 50 l/min. If tractor does not have an adjustable flow distributor, make sure that flow does not exceed 50 l/min.
000 293 390 0 - ABA Load Sensing Rollant 255 Uniwrap
35
