Installation
GB
Screw front hexagon nut (see arrow) by hand onto the threaded rod with contact washer. Screw two hexagonal nuts all the way onto the eye bolt (14) and push on contact washer.
14
Insert eye-bolt (14) into strap on tube and fasten with one hexagon head bolt (15) onto pump holder (A) by hand. 15
(fig. 14)
A
14 Mount V-belt (16) and tension by tightening the upper hexagonal nut on the eye-bolt (14). Lock upper hexagon nut with the lower hexagon nut.
10 14
Tighten the hexagon head bolt (15). Fasten front hexagon nut onto the threaded rod (10). Torque = 100 Nm (fig. 14, 15)
16
15 Attach hose line (A) onto rotary transfer joint for the version with variable speed gear cutterbar. (fig. 16)
A
16 Screw the screw-on iron (17) by hand to the adjusting pump with a hexagon head bolt (18). 17
(fig. 17)
18
17
299 424.0 - ABA HHA - LEXION 460–410
5.5
