Modification of the rear plate

V

C

D B A 18 MODIFICATION OF THE REAR PLATE

Drill an elongated hole (40 mm diameter) into the rear plate (V) with the following dimensions: –A = 210 mm –B = 170 mm –C = 130 mm –D = 122 mm (Fig.19)

Repaint drilled area. Attach the three stickers for the lubrication (4) vertically on the right hand side of the elongated hole.

19
