Conversion to pushed rear combination Hydraulics

• Fit gauges (1) and (2) on holder (6) with contact washers (5) and hexagon nuts (4).

4

A16 (1x)

5

M16x1.5 (1x)

5 (Fig. 31, 32)

4

32

• Attach and tighten hoses (3) to gauges (1) and (2).

(Fig. 33)

3 33

Fitting the hydraulic lines

• Remove cover (1).

1

(Fig. 34)

34 Frame, left P2

Remove hydraulic hoses (P2) and (LS) from the frame:

2

• Remove covers (2) and (3).

(Fig. 35) 3

LS 35
