Conversion to pushed rear combination Installing the wiring harness for the control panel
INSTALLING THE WIRING HARNESS FOR THE CONTROL PANEL Frame, right
• Remove and store clamp (1). (Fig. 21)
1 21
• Remove bolt (3). • Release clamp (2) from frame. • Take cable (4) from control panel out of the
4
clamp (2).
• Refit clamp (2) to the same position on the frame. 3
(Fig. 22, 23)
2
22
3
23
200
ZBA/UBA DISCO 9300 C Duo / DISCO 9300 RC Duo / 8600 C Duo - 00 0290 307 3
