Conversion to pushed rear combination Moving the ball retainers
MOVING THE BALL RETAINERS Frame, front 1
• Remove upper link pin and ball sleeve (1). • Remove lower link pin and ball retainers (2). (Fig. 5)
2
5 Frame, rear 1
• Fit upper link pins and ball sleeve (1) and use washers (3) to ensure there is no play.
• Fit lower link pins and ball retainers (2) and use washers (3) to ensure there is no clearance. (Fig. 6, 7, 8)
2 6
2
3
7 2
3
8
