Assembly - pushed rear combination
Assembly - pushed rear combination General instructions for assembly
5 Assembly - pushed rear combination GENERAL INSTRUCTIONS FOR ASSEMBLY Danger! Work on the machine/front attachment only when the engine is at a standstill. – Remove the ignition key!
77383
1
The text and illustrations are kept as neutral as possible. Text notes indicate the differences between the individual types.
• Carefully follow the illustrative representations for assembly.
• Keep to the sequence of operations.
10
ZBA/UBA DISCO 9300 C Duo / DISCO 9300 RC Duo / 8600 C Duo - 00 0290 307 3
