Prior to Operation Reinstating JAGUAR 880 / 860 / 840 / 820 (In this section, the item numbers in the pictures refer to the parts list in the fitting instructions.)
Unscrew the hydraulic hoses (H) and (76) from the right-hand lifting cylinder (66). Close off the feed line (76) to the pressure switch. 76
Remove the right-hand hydraulic cylinder (66). (Fig. 60)
H
Unscrew the hydraulic hose at the left-hand hydraulic cylinder. Fit the old hydraulic cylinders on the left and right hand sides and connect the hydraulic hoses.
66
67305
60 The tank return line (49) can remain on the valve block under the left-hand side cladding. (Fig. 61)
49
67159
61 Separate the hydraulic line (H) from the mower unit, from the tank return line (49). Close off the tank return line.
49
(Fig. 62)
H
67300
62
