Prior to Operation Increasing the lifting speed 1
JAGUAR 880 / 860 / 840 / 820: 2
3 Danger! Take particular care when working with pressure accumulators! Pressure accumulators are under high pressure! Assembly and repair work to the hydraulic system with pressure accumulator may only be carried out after releasing the fluid pressure.
68288
25 In order to increase the lifting speed of the complete mower unit (forage harvester lifting cylinder), pressure accumulators (1), (2) and (3) on the forage harvester can be removed. After removal, close the openings with screw plugs (4) (CLAAS ordering no.: 0213 101.0).
4
4
4
(Fig. 25, 26)
Note! 68289
0294 175.2 - BA DISCO 8700 C Plus / 8700 C
26
Conversion work on the pressure accumulators may only be carried out by CLAAS specialist workshops.
6.13
