Prior to Operation DISCO 8550 C Plus / 8550 C / 8550 C-T:
DISCO 8550 C Plus / 8550 C / 8550 C-T
• Fit the hydraulic lines (7) to the hydraulic cylinders (2).
• Unscrew the plug from the elbow unions (10) and 10
connect the hydraulic hoses (7) to the middle mower unit.
7
(Fig. 26, 27) DISCO 8500 C:
• Fit the hydraulic lines (7) to the hydraulic 10
cylinders (2).
7
• Fit the hydraulic lines (7) in front of the flow divider (9) with a T-union (8).
26
(Fig. 28) DISCO 8550 C Plus / 8550 C / 8550 C-T
7
10
2
68291M01
0293 653.9 - ZBA+BA DISCO 8550 C Plus / 8550 C / 8550 Plus / 8550 / 8550 C-T / 8500 C
