SERVICE AND REPAIR MANUAL Type : Drawing no.: Valid as of serial no. : Preparation of data : Author:
CL 19 Transfer case in CLAAS SFM Grassland machine VGZ 75-521 01 22.01.2007 Rauh
2.4.1.2 Installation of the washer package Package No. 1 Package No. 2 Package No. 3 Package No. 4
4 pc Washer 7315.169 will installed between case and cylinder housing enclosed 6 pc Washer 7315.169 will installed between case and cylinder housing enclosed 8 pc Washer 7315.169 will installed between case and cylinder housing enclosed 10 pc Washer 7315.169 will installed between case and cylinder housing enclosed
The installation position for the gasket and washers is in fig.14 represented.
Figure 14 With this adjustment is reached, that in shift position „1st. Gear“ the axial distance between shifting sleeve and spur gear („1st. Gear“) has approx. 2.0 – 3.0 mm behaves. The desired shift overlap is guaranteed with this. 27
