SERVICE AND REPAIR MANUAL Type : Drawing no.: Valid as of serial no. : Preparation of data : Author:
• •
•
CL 19 Transfer case in CLAAS SFM Grassland machine VGZ 75-521 01 22.01.2007 Rauh
Pull shifting rod outside by hand till the shifting sleeve is stopped on the spur gear. (1. Gear) Gap „s“ = 0 mm. Measure overlying length of shifting rod till the cylinder- contact surface of the transmissions housing (Fig. 13). Measure „L 3 “ = ..........mm.
Fig.13
25
