SERVICE AND REPAIR MANUAL Type : Drawing no.: Valid as of serial no. : Preparation of data : Author:
CL 19 Transfer case in CLAAS SFM Grassland machine VGZ 75-521 01 22.01.2007 Rauh
2.4.1.1 Adjustment of Shift Cylinder Purpose: Adjust of the axial position for the shift cylinder, with matched washer package. To prevent that the required overlapping of the gear tooth shifting in the first speed fell not becomes. Procedure: • Insert first speed. The shifting rod is pulled by hand to the cylinder housing outside up till the stop of the piston at this. Measure the axial distance between the shifting rod front side to the front end cylinder housing. (Fig. 11). • It’s also possible to measure this distance before inserting the complete shift cylinder. • Measure „L 1 “ = .......mm.
Fig. 11
• •
Loose fixing screws and remove cylinder housing with gasket from the shifting rod. Measure length of the cylinder housing. (Fig. 12).
• Measure „L 2 “ = ..........mm.
Fig.12
24
