SAFETY Identification
Lifting kit reference 77 11 132 317
For the location of the structure identification plates :
Safety measure
– Type series N°. – Certification N°. – ID N° of the safety structure, refer to the user manual, chapter (A) Important : A safety structure damaged (distorted) as the result of an accident, must never be repaired but must be replaced
To raise the cab, always use a hoist in perfect working order, with a sufficient hook height to enable the cab to be lifted clear. If the cab is partly lifted, it must be propped up. – Position the tractor on flat and level ground – If the tractor is equipped with a suspended axle, put it in the low position – Chock the wheels.
Recommendations before raising
– Place warnings around the working area.
Important : lRaise the cab only with a spreader bar to avoid any risk of deformation to the lifting points.
– Use certified shackles.
– Cab weight : About 750 kg
– Respect safety instructions. Wear protective gloves and shoes
Spreader bar reference nr 77 01 388 907 .
– Use a certified hoist in perfect working order. – Use certified slings in perfect working order
Forbidden
Use spreader bar only
.
Fig. 1
841hsm03
H1.2
Arion 630-610 C – 08.2008 – GB
