A/C / Heating Removing the dehydrator filter E Important : If maintenance operations on the system are to be prolonged (over 15 minutes), plug all system component orifices to prevent internal condensation and oxidation. – Disconnect the AC duct (A).
A
E D
B
C
– Loosen clamps (B) and Remove the filter (C).
H
Refitting the dehydrator filter Important : At each refitting, change the O-rings and lubricate the new O-rings with oil n°60 05 700 299.
G
– Pour 15 ml oil n°60 05 700 299 into the new dehydrator filter. – Refit the filter (C) onto its bracket..
644msm00
Fig. 2
Removal of the condenser Important : If maintenance operations on the system are to be prolonged (over 15 minutes), plug all system component orifices to prevent internal condensation and oxidation. – Remove the fuel cooler (H). – Remove the dehydrator filter (C). – Disconnect the AC duct (D). – Undo the 2 screws (E) and the 2 screws (F). – Removal of the condenser (G).
Important : At each refitting, change the O-rings and lubricate the new O-rings with oil n°60 05 700 299. – Pour 30 ml oil n°60 05 700 299 into the new condenser – Fit the condenser (G) and Tighten the screws. – Tighten the AC ducts.
