Removing the cab Installing the spreader bar Important : The screws must be screwed tightly into the lifting supports on the cab. The load must be lifted vertically. Before lifting, check the state of the screws, especially the threads, and check for distortion. If necessary, replace with screws n° 77 03 001 749 only.
Operation n° 3 – Use lifting bar n° 77 01 388 907 and the screws and washers of kit n° 77 11 132 317. – Screw in the lifting screws tightly at the points provided. – Centre the lifting bar.
841msm01
Fig. 5
841hsm06
Fig. 6
845msm32
Fig. 7
Operation n° 4 – Lift the single cover. – Remove the engine side covers.
H1.6
Arion 630-610 C – 08.2008 – GB
