NSP_R
Service Manual
5.1.2
Hoist points
Figure 21 below indicates the correct hoist points for hoisting the truck up for maintenance. Make sure that the capacity of the lifting device is sufficient.
Figure 21. Hoist points
5.2
Transportation
When transporting the truck, it is important that you secure it safely to prevent it from moving. Also support the traction wheel with blocks and lower the mast. If the truck is equipped with an operator’s platform, lift the operator’s platform up. CAUTION Do not tie the truck from the tiller arm or it may break.
Figure 22 below shows an example on how to secure the truck safely for transportation.
Copyright© 2013 by MCFE. All rights reserved.
Revision: B
Document ID: 616843
39 (338)
