15.10 Driving speed reduction With duplex masts with two side cylinders and triplex masts, the driving speed is reduced by 0.5 km/h after a 1,000 mm lift. With duplex and triplex masts with free lift, the driving speed is reduced by 0.5 km/h after the free lift.
15.10.1 Driving speed reduction sensor Type
Magnetic reed switch
Size
Flat rectangular 9 mm x 13 mm x 44 mm
Vs
0 – 200 VAC/VDC
Switching output
Bi-stable contact with an S actuating magnet
Electrical wiring
DC 2-wire, Vs = BRN, GND = WHT
Sensing range
Up to 60 mm, depending on the actuating magnet
Spare part
RL609813
15.10.1.1 Installation of the driving speed reduction sensor (duplex mast with two side cylinders and triplex mast)
Figure 144. Driving speed reduction sensor overview (duplex mast with two side cylinders and triplex mast)
