Figure 3.19. Checking the brake pad thickness 4.
After checking/replacing the brake pad, clean the brake unit from any accumulated dust with pressurised air. Follow work safety procedures when using pressurised air and use a low pressure.
5.
After the above procedures, reattach the brake unit to the drive unit.
3.7.5.2. 1,600 kg capacity trucks Check the wear of the brake pad by measuring the air gap. If the air gap is within acceptable limits, only cleaning the brake with pressurised air is necessary. To service the brake: 1.
Remove the rubber gasket over the brake air gap.
51
