5.1.1.3. Fast mast lowering
Figure 5.11. Hydraulic fluid flow during fast lowering
122
1.
The operator also activates the second tiller switch for lowering. The pressurised hydraulic fluid flows from the mast cylinders through two strainers.
2.
The fluid flows through the magnetic valves (2Y1 and 2Y2).
3.
The fluid flows through the flow restrictor back to the tank.
