NO20NE/20NEP/10NEF/10NEFP/20NEX/20NEXP
Service Manual
15.21 Pedestrian control buttons NOTE: The pedestrian control buttons are not available for the NTR30N tow truck.
Figure 163. Pedestrian control buttons overview 1. 2.
Truck forward button Stop button
3.
Buttons for lifting and lowering the forks
With the pedestrian control buttons, you can use the order picker truck while you walk alongside the truck. Use the truck forward button to move the truck forward. Before you move the truck, make sure that the wheels point straight forward. Use the stop button to stop the truck. Use the buttons for lifting and lowering to move the forks. Push the arrow-up button to lift the forks and push the arrow-down button to lower the forks.
Copyright© 2015 by MCFE. All rights reserved.
Revision: A
Document ID: 624877
332 (352)
