NO20NE/20NEP/10NEF/10NEFP/20NEX/20NEXP
Service Manual
15.14 Drive alarm
Figure 153. Drive alarm overview
The drive alarm is used to tell people about a truck in operation.
15.14.1 Install the drive alarm 1. Open the front cover. See section 5.4.1. 2. Install the drive alarm to the mounting plate of the motor fan. 3. Connect the connector of the drive alarm.
4. Connect the drive alarm wires. See the schematic diagram of the truck model. See Figure 154 below. 5. Set the parameter AUX OUTPUT to Level 7.
Copyright© 2015 by MCFE. All rights reserved.
Revision: A
Document ID: 624877
317 (352)
