NO20NE/20NEP/10NEF/10NEFP/20NEX/20NEXP
Service Manual
15.10 Quick battery replacement NOTE: The quick battery replacement option is installed to the truck during manufacturing. Thus, this option must be selected before you buy the truck.
15.10.1 Remove an empty battery with the battery replacement device CAUTION To prevent injury, do not put your foot between the rollers of the battery replacement device when you pull the battery onto the battery replacement device.
1. 2. 3. 4.
Park the truck in the battery changing area. Apply the parking brake. Set the power of the truck to OFF. Open the battery cover. See section 5.4.6.
5. Disconnect the battery connector.
6. Adjust the height of the battery replacement device with a pallet truck until the top of the rollers of the battery replacement device and the rollers of the truck are at the same level.
Copyright© 2015 by MCFE. All rights reserved.
Revision: A
Document ID: 624877
309 (352)
