NO20NE/20NEP/10NEF/10NEFP/20NEX/20NEXP
15.9
Service Manual
Charger connector
Figure 148. Charger connector overview
NOTE: Make sure that you set the mechanical voltage selector to the correct battery voltage (24 V)! Also record the polarity of the battery cables.
15.9.1
Replace the charger connector
1. Remove the screws that hold the charger connector in position. 2. Remove the wires. 3. Remove the charger connector.
