NO20NE/20NEP/10NEF/10NEFP/20NEX/20NEXP
15.6
Service Manual
Folding seat
Figure 145. Folding seat overview
The folding seat option makes operating the truck more ergonomic. You can use the folding seat as a seat and as a backrest.
15.6.1
Install the folding seat
1. Install the mounting bracket of the folding seat to the truck with screws. 2. Install and tighten the screws that attach the mounting bracket to the truck.
3. Install the folding seat to the holding plate with screws.
Copyright© 2015 by MCFE. All rights reserved.
Revision: A
Document ID: 624877
304 (352)
