MARINE JUNCTION BOX
MARINE JUNCTION BOX SINGLE 225-6122 DUAL 225-6123
The Marine Junction Box (MJB) performs two functions. The first function the MJB can be used for is a stand-alone junction box for any marine application. The MJB can be used with the custom “made to length” wiring harness to make installation easier and less time consuming. The MJB is also used in the MSCS to provide the interconnection between the engine ECU and PCP. Inside the PCP there are two separate wiring sections, one for the port system and a second for the starboard system. These sections provide the interconnection points for engine power and vessel control and monitoring. The MJB also provides circuit protection for the PCP, ECU, and the other components connected to the MSCS.
Multi-Station Control Installation Guide
45
