WING STATION
WING STATION 255-8006
The Wing Station can be installed on a flat panel or in a swing-open door. The control head is fully protected from sea and weather elements. This control head is designed for installation in wing stations and aft stations that are used for docking of the vessel. With the exception of the throttle and gear controls, the functionality is similar to the Integrated Control Head button panel. Wing Station provides engine throttle control through the use of port and starboard rotary throttle controls. Transmission control is provided through the use of toggle switches for forward, neutral, and reverse. A button panel also provides operator input switches for station activation, throttle synchronization, slow vessel, trolling, and gear lockout. Wing Station provides a visual indication of switch status (LED) and is available for a dual engine configuration. It communicates directly with the Powertrain Control Processor (PCP) via the control station data link.
