PARTS LIST
118
Part Name
Part Number
Description
Marine Junction Box – Twin Engine
225-6123
Twin Engine Marine Junction Box
Marine Junction Box – Single Engine
225-6122
Single Engine Marine Junction Box
Trunk Harness 225-6116
Made-to-length harness that connects the ECU customer connector to the MJB. One cable is required per engine. Length 225-6117
Start Stop Control Panel 217-3865
Start/stop panel with keyswitch, remote shutdown switch, and warning and diagnostic lamps. Requires 210-8772 or 210-8773 (for use with 217-8191) gaskets
Sync Switch Panel 217-8191
Sync switch panel, sync and slow vessel mode functions. Requires 217-3865 and 210-8773.
Keyswitch/Alarm 226-3423 Breakout Panel
Keyswitch/alarm breakout panel – connects keyswitch, PCP alarm, remote shutdown switch, remote start, diagnostic lamp, warning lamp, minus battery, and plus battery. Requires 226-0361 or OEM supplied wiring.
Keyswitch/Alarm 226-0361 Breakout Panel Wiring
Made-to-length cable that connects the keyswitch/alarm breakout panel to the MJB. Length 226-0362
Marine Power Display
MPD display with application code
267-8623 259-2171
Marine Power Display 259-2170
MPD display without application code (blank display)
Marine Power Display 291-4310 Mounting Kit
MPD mounting kit
Marine Power Display Bracket
208-0590
MPD mounting kit – gimbal mount
6-Pin Termination Resistor
208-0432
Termination resistor
6-Pin Tee Connector 221-9506
Six-pin tee connector – connects components and drop harnesses into the CAN or J1939 data link harness
MPD Drop Harness 225-6112
Made-to-length MPD drop harness to connect the MPD display into the J1939 data link trunk harness. Length 225-6114.
MAPD Interface Module 274-8068
Used to convert the J1939 into the gauge data link.
MAPD Harness 212-8259
Cable to connect from the 3-pin tee to the 6-pin MAPD interface module connector. Cable has 155-2273 plug assembly.
Multi-Station Control Installation Guide
