1-33 System Operation Section MD6750 Blasthole Drill
BI011043_EN OPERATOR’S CONTROL CONSOLE NOTE:
The controls on the operators console are all electric. The switches operate electric controls, electromechanical or electrohydraulic valves on the machine. For purpose of describing the controls, the console will be broken down into panels and the controls on each panel described. The panels of the console are: main controls, propel controls, selector switches, leveling controls and Operator’s display terminal.
Operator’s Control Console - Overall View
NOTE:
The panels with controls as shown on the following pages are typical of what could be included on a console. Individual machines will vary depending upon customer requirements.
