1-54 System Operation Manual MD6640 Blasthole Drill
BI012593
MISCELLANEOUS CONTROLS Located about the machine are various miscellaneous controls and monitors which would be used with optional equipment or do not fit in the previously described groups.
PORTABLE REMOTE PROPEL STATION (Optional) The portable remote propel station is located in an enclosure under the operator’s cab on the right side of the machine. In addition to storing the portable station the enclosure includes 40 feet of cable and an enabling switch to energize or de-energize the station. Another enabling switch and plug in socket are located at the front left corner of the drill main frame. The station includes two joysticks, one for each crawler frame; an emergency stop push-button; a propel speed selector; and a red indicator which will light up when the station is energized.
PORTABLE REMOTE PROPEL STATION
