OPERATOR’S DISPLAY The operator’s display provides the operator with an interface to the machine and it’s functional areas. From this informational display, the operator can make inputs that effect machine operation, monitor systems and make system adjustments. Through this display terminal the operator will receive pertinent fault data to identify potential problems and prevent machine damage.
OPERATOR’S DISPLAY MONITOR
Refer to a separate manual for further operational procedures for the Operator’s Display Monitor. The display monitor is mounted on a tilt-swivel bracket on the left control console. Individual operators can position the screen in any desired position.
DISPLAY AREA & INDICATORS The display area of the monitor screen is the large area in the center of the screen. This area is “touch sensitive.” All information will be displayed on this area either in a text format or in the form of visual icons. The buttons and icons that appear on the screen will respond to touching the screen in the appropriate area of the icon. These icons and buttons will react by activating the screen, switch activation or display information relevant to the icon. The switches and buttons will be covered in the following pages under the screen topic in which they appear.
