ATTACHMENT CONTROLS Control Levers Three separate control levers are provided in the operator’s compartment. These controls operate the machine’s lift and tilt functions, operate the attachments and winch. The four-way joystick control operates the machine’s lift and tilt functions. The lever has five positions tilt back, tilt forward, lift, lower and hold. The lever is spring centered to the hold position. The No. 1 and No. 2 two-way hydraulic control levers operate the winch and PTO. These levers have three positions up, down and hold. The levers are spring centered to the hold position. The oil pressure for these controls is supplied from the main control manifold at a reduced pressure of 650 psi. No. 1- Two-Way Hydraulic Control Lever
No. 2- Two-Way Hydraulic Control Lever
Two-Way Control Levers
Four Way Joystick
Maintenance Inspections are to be carried out on the four-way joystick and two-way control levers as per Preventative Maintenance Inspection Schedules. 1) Inspect the control lever boots for damage. 2) Inspect operational performance. Replace any worn or damaged parts and retest the operation of the machine or system.
