Method Of Operation
4:1 Fit suitable lifting equipment to the rear casing of the transmission.
4:2 Invert the transmission on a suitable bench. For safety and convenience the bench should have hole in it to accommodate the input shaft and reaction shaft.
4:3 Remove the 4 plastic plugs and cap screws, and remove the Dual modulating valve.
4:4 Remove the 4 O Ring seals from the Dual modulating valve.
4:5 Remove the Clamp Bolt and retaining clamp and remove the Speed sensor from the transmission.
4:6 Remove the Cap screw and clamp from each of the clutch solenoid valve assemblies
45
